DRIVEConn® MT - SERVO

DRIVEConn® MT - SERVO

DRIVEConn® MT Power & SERVO Cables are specialized cables designed for use in servo motor systems, which are commonly used in industrial automation, robotics, CNC machinery, and other precision control applications. These cables play a crucial role in ensuring the reliable and efficient operation of servo motors. Here are some key considerations and features of servo cables:

  • High Flexibility
  • Shielding:
  • High-Quality Insulation
  • Oil and Chemical Resistance
  • Temperature Resistance
  • Connector Compatibility
  • Strain Relief:.
  • Abrasion Resistance
  • Customization
  • Compliance
When selecting servo cables for your application, it's essential to consider the specific environmental conditions, voltage and current requirements, and motion dynamics of your system. Choosing the right cables ensures the overall performance and longevity of your servo motor system. Additionally, consulting with cable manufacturers or suppliers with expertise in servo applications can help you make informed decisions..

SERVO eq. BOSCH REXROTH®
SERVO eq. BOSCH REXROTH®
BP DP HP

Performance Levels

Basic Performance

Cables for static application or for installations with minimal and infrequent movements, and bending. PVC sheath anti-oil, flame retardant and resistant to most industrial oils. Also suitable for installations in humid areas. The cables are UL/CSA standard (where required) and UL LISTED (where indicated).

Salient Features

  • Temperature: Static: -30 °C / +90 °
  • Bend radius: 10 x O.D.
  • Speed: 180 m/min
  • Acceleration: 2.0 m/sec2
  • Operating cycles: 200,000
Dynamic Performance

Cables for cable chain application. PVC sheath anti-oil, flame retardant and resistant to most industrial oils. Also suitable for installations in humid areas. The cables are UL/CSA standard (where required) and UL LISTED (where indicated).

Salient Features

  • Temperature: Static: -25 °C / +90 °
    Dynamic: -40 °C / +90 °
  • Bend radius: 6.5 x O.D.
  • Speed: 300 m/min
  • Acceleration: 20 m/sec2
  • Operating cycles: 5,000,000
High Performance

Cables for application in high performance cable chains. PUR sheath, halogen-free, flame retardant and resistant to most industrial oils. Also suitable for installations in humid areas. The cables are UL/CSA standard (where required) and UL LISTED (where indicated).

Salient Features

  • Temperature: Static: -40 °C / +90 °
    Dynamic: -40 °C / +90 °
  • Bend radius: 6.5 x O.D.
  • Speed: 600 m/min
  • Acceleration: 60 m/sec2
  • Operating cycles: 10,000,000
